• Fits any T-100, S-100, or JP-100
• A reducing adapter may also be require

• Insulated cavity plug
• Extension height
• Adjustable Memory Stop
• Sleeved handle
• (2) tagging holes

The Jomar locking device prevents unauthorized use during maintenance or down-time. The locking device is attached over the stem and handle and held in place with an allen screw that is threaded into the center of the stem. With the padlock in place, the allen screw is not accessible, making it a tamper proof design. Will fit any T-100, S-100 or JP-100 series ball valve.

• Type 1: Fits 100 Series sizes: 1/4”, 3/8” and 1/2”
• Type 2: Fits 100 Series sizes: 3/4”
• Type 3: Fits 100 Series sizes: 1” and 1-1/4” Filterball sizes: 1/2”, 3/4” and 1”
• Type 4: Fits 100 Series sizes:1-1/2” and 2” Filterball sizes: 1-1/4” & 1-1/2”
• Type 5: Fits 100 Series sizes: 2-1/2” and 3” Filterball sizes: 2”

Designed to help control the flow in applications where precision throttling is needed

• Percentage flow rates printed on memory stop for precise flow control
• Vibration free self-locking nut
• Fits on any T-100, S-100 or JP-100 series ball valve

Installation

Designed to be assembled on top of the stem assembly for easy and accurate flow control.

1. Remove handle nut (leave handle in place).
2. Slide numbered plate on stem over valve handle.
3. Replace and tighten handle nut.
4. With valve in full open position, place memory indicator on top of handle and over handle nut positioned at 100. This should place the indicator tail behind the handle stop.
5. Loosely tighten down hex cap screw supplied with memory kit.
6. While holding memory indicator tail, turn valve to desired opening and tighten.

The Jomar Long-Neck T-Handle is ideal for applications where piping will be insulated. Fits on any T-100, S-100 or JP-100 series ball valve.

Specifications

• Type 1: Fits sizes 1/2” T-100 Series
• Type 2: Fits size 3/4” T-100 Series
• Type 3: Fits sizes 1” and 1-1/4” T-100 Series

The Jomar Slow-Ball is a 270̊ gear-closing handle that allows metering of the fluids under high pressure thus preventing a potential water hammer situation in the pipe. Fits on any T-100, S-100 or JP-100 series ball valve.

Specifications

• Type 1: Fits sizes 1/4”, 3/8” and 1/2”
• Type 2: Fits size 3/4”
• Type 3: Fits sizes 1” and 1-1/4”
• Type 4: Fits sizes 1-1/2” and 2”

• Fits any T-100, S-100 or JP-100

• Fits any T-100NE and JP-100G

• Fits only T-100NE

• Fits any T-100, S-100 or JP-100

• Fits any T-100, S-100 or JP-100

• Fits any T-84-M

• Fits any T-100, S-100 or JP-100

• Fits any T-SS-2002N-DUE

• Fits any JF-100G, T/S-422G, T-423G

• Fits any JF-100T/S, T/S-110, T-100HF, S-100HS, T/S-422G, T-423G

• Fits any JF-100T/S, T/S-110, T-100HF, S-100HS, T/S-422G, T-423G

• Fits any JF-100T/S, T/S-110, T-100HF, S-100HS, T/S-422G, T-423G

• Fits any JF-100T/S, T/S-110, T-100HF, S-100HS, C-402, T/S-422G, T-423G

• Fits any JF-100T/S, T/S-110, T-100HF, S-100HS
