• Insulated Cavity Plug
• Extension Height
• Adjustable Memory Stop
• Sleeved Handle
• (2) Tagging Holes

• Insulated Cavity Plug
• Extension Height
• Adjustable Memory Stop
• Sleeved Handle
• (2) Tagging Holes

The Jomar Slow-Ball is a 270̊ gear-closing handle that allows metering of the fluids under high pressure thus preventing a potential water hammer situation in the pipe.

Specifications

• Type 1: Fits sizes 1/4”, 3/8” and 1/2”
• Type 2: Fits size 3/4”
• Type 3: Fits sizes 1” and 1-1/4”
• Type 4: Fits sizes 1-1/2” and 2”

Designed to help control the flow in applications where precision throttling is needed

• Percentage flow rates printed on memory stop for precise flow control
• Vibration free self-locking nut

Installation

Designed to be assembled on top of the stem assembly for easy and accurate flow control.

1. Remove handle nut (leave handle in place).
2. Slide numbered plate on stem over valve handle.
3. Replace and tighten handle nut.
4. With valve in full open position, place memory indicator on top of handle and over handle nut positioned at 100. This should place the indicator tail behind the handle stop.
5. Loosely tighten down hex cap screw supplied with memory kit.
6. While holding memory indicator tail, turn valve to desired opening and tighten.

The Jomar handle extensions are available for applications where it is necessary to extend the valve handle approximately 2” higher from it’s original position. Fits on the T/S-200CSSG and T/S-200CSS series ball valve.

Specifications

• • Type 1: Fits sizes 1/4”, 3/8” and 1/2”
  • Type 2: Fits size 3/4”, 1" and 1-1/4"
  • Type 3: Fits sizes 1-1/2” and 2"

The Jomar handle extensions are available for applications where it is necessary to extend the valve handle approximately 2” higher from it’s original position. Fits on any T-100, S-100 or JP-100 series ball valve.

Specifications

• • Type 1: Fits sizes 1/4”, 3/8” and 1/2”
  • Type 2: Fits size 3/4”
  • Type 3: Fits sizes 1” and 1-1/4”
  • Type 4: Fits sizes 1-1/2” and 2”
  • Type 5: Fits 100 Series* sizes: 2-1/2” and 3”

The Jomar handle extensions are available for applications where it is necessary to extend the valve handle approximately 2” higher from the original position.
